Model No.: SFF-568 Slim Micro ATX
Audio/Microphon: HD-Audio
Front I/O: 6 USB + 1 Type C Ports, Power button
Driver bays: 3.5''HDD*1 or 2.5''SSD*1 on CD Driver, SSD*1 on bottom
Chassis size (LxWxH) / (MM): L355*W103*H325 mm
Production size(LxWxH) / (MM): L385*W103*H325mm
Carton size (LxWxH): L420*W140*H367mm
Chassis: 0.6mm, SPCC
PCI: 4
Max.Graphics card: 220mm
Max.CPU Cooler(Height): 80mm
Front panel: ABS
Side panel:Steel
PSU Support:TFX (Black), SFX(Front)
MB form factor: M-ATX/ITX
Dust-proof magnetic filter Yes
SD/CF reader: Optional
USB3.0: Optional
